PV Input 500VDC MPPT Hybrid Solar Inverter Pure Sine Wave OEM

Product Categories
Shenzhen Zhongguanda Technology Co., Ltd.
Contact Now

PV Input 500VDC MPPT Hybrid Solar Inverter Pure Sine Wave OEM

  • 1
  • 2
  • 3

Place of Origin : China

Brand Name : ZGDUPS

Model Number : NKH-3.2KW

Packaging Details : one set in a box

Supply Ability : 10000 Piece/Pieces per Month

Price : $320.00/pieces 1-10 pieces

Max. PV Array Power  : 5000W

Max. PV Array Open Circuit Voltage  : 500VDC

Transfer Time : 10 Ms (For Personal Computers)

OEM : Accepted

Application : Home Solar Power System

Waveform  : Pure Sine Wave

Contact Now

PV Input 500VDC MPPT Hybrid Solar Inverter Pure Sine Wave OEM



Specification

Max. PV Array Open Circuit Voltage 500VDC
Max. PV Array Power 5000W
Operating Voltage MPPT Range 120-450VDC
Battery Overcharge Protection 33VDC
Max. Solar Charge Current 100A
Max. AC Charge Current 100A
Max. Charge Current 100A
Dimension 100 x 300x 440mm
Net Weight 7.8KG
Communication Interface USB/RS232
Humidity 5% to 95% Relative Humidity (Non-condensing)
Operating Temperature 0°C-55*C
Storage -15*C-60°C



MAIN FEATURES:

  • High effciency pure sine wave inverter (PF=1).
  • Wide PV input range (120Vdc-500Vdc) 100A MPPT SCC.
  • 4 Intelligent 3 stage 100A AC battery charger.
  • Intelligent functionality enables utility & solar input prioritization.
  • Monitor, troubleshoot, or communication with USB/RS232.
  • System configures quickly into compact, wall-mounted system.
  • Enhance MPPT solar charge controller up to 4000 WATTS.
  • Efficiently works without battery.

PV Input 500VDC MPPT Hybrid Solar Inverter Pure Sine Wave OEMPV Input 500VDC MPPT Hybrid Solar Inverter Pure Sine Wave OEMPV Input 500VDC MPPT Hybrid Solar Inverter Pure Sine Wave OEM
